MicroCap 9 Capnograph/Oximeter

MoveOxy™ Pulse Oximetry Equipped with MoveOxy™ advanced digital Sp02, the MicroCap 9 handheld Capnograph and Oximeter is capable of severe monitoring conditions, providing reliable Sp02 and pulse rate measurements.

• Accurate monitoring even with weak pulse signals.
• Reliable monitoring in motional situation.
• Provides graphical trends and plethysmographic waveform

TECHNICAL SPECIFICATIONS EtC02/C02

• EtC02/C02 range: 0 -150mmHg(0-20kPa,or 0-20%(V/V))
• Accuracy: ±2mmHg when 0-40mmHg ±5%(reading) when> 41-70mmHg ±8%(reading) when > 71-100mmHg ±10%(reading) when> 101-150mmHg
• Update: Every breath, 10sec, 20sec or 30sec selectable
• Trend length: 24 hours

RESPIRATION RATE

• Range: 3-150t/min
• Accuracy: ±1 %(reading) or ±1 times/min whichever is greater
• Trend length: 24 hours
• Flux: 50-250cc/min selectable

SpO2

• Oximetry saturation range: 0-100%
• Accuracy: ±2% when 70-100% ±3% when 50-69%
• Trend length: 24 hours

PULSE RATE

• Range: 30-250 bpm
• Accuracy: ±2bpm or ±2%(reading) when 30-250bpm
• Trend length: 24 hours

POWER

• AC input: 100V-250V, 50Hz/60Hz
• AC power consumption: 5W

OPERATION

• Working temperature: 5-40 ºC
• Humidity: 30 - 75% (non-condensing)
• Atmospheric pressure: 86 - 106kPa

BATTERY

• Battery type: Built-in rechargeablelithium battery
• Battery capacity: 3.6V, 3000mAh
• Working time: 10 hours

PHYSICAL DATA

• Dimension: 70mm(W) x 160mm(H) x 40mm(D)
• Weight: 600grams

LANGUAGE

• English
• Spanish
• Dutch
