STIMPOD NMS450X Nerve Stimulator and TOF Monitor

Description

Stimpod NMS450X Nerve Stimulator and TOF Monitor is the first of its kind QTOF monitor offering both AMG and EMG technology.

Inservice Videos

• Stimpod 450X AMG/EMG Inservice
• Stimpod 450X Operational Inservice

Training Videos

• Ulnar Nerve TOF Monitoring
• Supramaximal Stimulation
• Posterial Tibial Nerve TOF Monitoring
• Facial Nerve TOF Monitoring
• EMR Train-of-Four and Post-Tectonic Count

AMG and EMG Set-up and Quick Start

• AMG Set-up and Quick Start
• EMG Set-up and Quick Start

EMG Showcase by Xavant

• EMG Showcase Video

EMR Connectivity

• EMR Connectivity Sheet

Quantitative Train-of-Four Endorsements

•  2023 ASA Anesthesia Practice Guidelines Summary
• ASPF February 2016 Monitoring of Nuromuscular Blockade
• ASPF February 2016 Multi-Faceted Iniatiative TOF, Sugamadex
• IARS Anesthesiology News Consensus Statement for Objective Monitoring

Stimulating Modes

• Train-of-Four (TOF)
• Double Burst (DB)
• Post-Tetanic-Count (PTC)
• Tetanus (TET)
• Twitch (1Hz, 2Hz, 5Hz)

Current Range

• Nerve Locating: 0.0 – 5.0mA
• Nerve Mapping: 0 – 20mA
• NIMBA Monitoring: 0 – 80mA

Load Impedance

• Nerve Locating: 0 – 20kΩ (100V)
• Nerve Mapping: 0 – 20kΩ (400V)
• NIMBA Monitoring: 0 – 5kΩ (400V)

The Xavant STIMPOD NMS450X Nerve Stimulator and TOF Monitor includes a Tri-axial accelerometer which provides real time feedback of the strength of contraction of the affected limb (Train Of Four, Double Burst and Post Tetanic Count modes only). The strength of each measured contraction is displayed on the STIMPOD NMS450X graphically and the relevant ratios are calculated and also displayed.

The fine movement differences that can be detected by utilizing accelerometry offer major advantages over gauging contraction strength visually or tactilely.

Tri-axial accelerometry calculates the movement vector of the contraction in three dimensions.  This negates the need for calibration as is the case with one-dimensional accelerometers, and reduces the setup time of the procedure.

Combined Nerve Mapping and Nerve Location:

Auto-sensing technology provides a solution for simultaneous nerve mapping and nerve location. The Xavant Stimpod NMS450X Nerve Stimulator monitors whether the mapping probe or needle touches the patient and adjusts the current range accordingly, ensuring quick and precise nerve location.

The Stimpod Nerve Mapping Probe was designed to enable transcutaneous nerve mapping at higher currents (to a maximum of 20mA), whilst the tip offers a contact surface small enough to ensure effective discrimination.

Featured Articles

• Xavant Technology Announces First Dual-Sensor Neuromuscular Patient Monitor
• The Cost of Postoperative Respiratory Adverse Events
• Why Quantitative NMT Monitoring is Critical in Surgical Patients and How Best to Do It
• Increased PACU Length of Stay – A Costly Matter

B170450 STIMPOD NMS450X NERVE STIMULATOR KIT INCLUDES:

• Xavant STIMPOD NMS450X Nerve Stimulator and TOF Monitor
• NMBA Monitoring Cable OR Nerve Mapping/Locating Cable
• Carrying Case
• Requires 4xAAA batteries, not included

B170450AE STIMPOD NERVE STIMULATOR KIT INCLUDES:

• Xavant STIMPOD NMS450X Nerve Stimulator and TOF Monitor
• AMG NMBA Monitoring Cable AND EMG NMBA Monitoring Cable
• Carrying Case
• Requires 4xAAA batteries, not included

*Related Products are replacement items.
